Denso High Voltage Water Heater 15kw 25kW DC 100W

Product Details

Place of Origin: CHINA

Brand Name: EVPTC

Certification: CE

Model Number: QA

Payment & Shipping Terms

Minimum Order Quantity: 1 SET

Price: $1200-1500 per set

Packaging Details: carton or wooden case packing

Delivery Time: 15-20days

Payment Terms: T/T

Supply Ability: 100 sets per 2 weeks

Get Best Price
Product Details
High Light:

denso high voltage water heater

,

high voltage water heater 15kw

,

high voltage heaters 15kw

Heat Output:
15-25KW
HV Voltage Range:
DC 250-870V
LV Voltage:
DC 24V Nominal
Efficiency:
> 95 %
Controllability Steps:
1%
Dimensions:
365*313*123mm
Weight:
9kg
Temperature Range For Heating:
-40 To 90 ℃
Temperature Range For Ambient:
-40 To 125 ℃
Communication:
CAN OR LIN
Dielectric Strength:
3500 V (DC)
IP Protection Class:
IP 67
EMC:
ECE R10 Rev. 5
Insulation Resistance:
>500MΩ
Service Life:
10 Years Or 10,000 Heating Hours
Heat Output:
15-25KW
HV Voltage Range:
DC 250-870V
LV Voltage:
DC 24V Nominal
Efficiency:
> 95 %
Controllability Steps:
1%
Dimensions:
365*313*123mm
Weight:
9kg
Temperature Range For Heating:
-40 To 90 ℃
Temperature Range For Ambient:
-40 To 125 ℃
Communication:
CAN OR LIN
Dielectric Strength:
3500 V (DC)
IP Protection Class:
IP 67
EMC:
ECE R10 Rev. 5
Insulation Resistance:
>500MΩ
Service Life:
10 Years Or 10,000 Heating Hours
Product Description

HVCH QA01 Series 15-25kW DC Heater w/ 100W Controllability Steps





In the modern sphere of scientific investigation, there is an ever-growing necessity for precise thermal regulation. The HVCH QA01 Series steps forward as a beacon of innovation in this sector, not merely functioning as a heater but evolving as a catalyst in the world of precise temperature governance. Specifically designed for sophisticated research environments, it guarantees precise, unwavering, and potent heating solutions, setting a new standard in the industry.





Specification:



HVCH QA01 Series
Heat Output     15-25kW
HV Voltage Range     DC 250-870V

LV Voltage

  DC 24V nominal
Efficiency     > 95 %
Controllability Steps     100W
Dimensions     365*313*123mm
Weight     9kg
Temperature Range for Heating     -40 to 90 ℃
Temperature Range for Ambient     -40 to 125 ℃
Communication     CAN or LIN2.1
Dielectric Strength     3500 V (DC)
IP Protection Class     IP 67
EMC     ECE R10 Rev. 5
Insulation Resistance     >500MΩ
Service Life     10 years or 10,000 heating hours









Denso High Voltage Water Heater 15kw 25kW DC 100W 0

Denso High Voltage Water Heater 15kw 25kW DC 100W 1











Product Attributes:





  • Supreme Water Resistance: Navigate the challenges of humid laboratory settings or unforeseen liquid spills with our resilient heater. Bolstered with an IP 67 certification, it stands as a testimony to our commitment to quality and durability.
  •
  • Accurate Performance Control: Equipped with the ability to finely tune the water outlet temperature and dictate the maximum heat output, this heater promotes an environment where precision is at the forefront.
  •
  • Double-tiered Safety Protocols: Integrating both mechanical and electronic safeguards, our heater is designed to prevent potential hazards effectively, promising a safe operational environment at all times.
  •
  • Complete Electrical Isolation: We have achieved a landmark development in ensuring complete segregation between water and electrical components, a critical safety prerequisite in laboratory equipment.
  •
  • Innovative PTC Technology: Leveraging state-of-the-art PTC technology, our heater dynamically modulates power output while steadfastly adhering to a designated temperature limit, enhancing reliability and efficiency.



Denso High Voltage Water Heater 15kw 25kW DC 100W 2





Applications:



Within the sophisticated arena of scientific discovery, precision stands as a cardinal necessity. The HVCH QA01 Series finds its niche in distinguished corporate entities and government laboratories, particularly excelling in the evaluation of thermal management systems, simulating realistic battery heating scenarios, and enabling swift startups in extremely cold conditions. Its potent combination of power, precision, and steadfast reliability make it a vital tool in groundbreaking research pursuits.







Our Services:

  • Direct Procurement: Streamline your acquisition process and cut costs by directly procuring from the manufacturer.
  •
  • Bulk Order Benefits: Avail of significant discounts when placing large orders, coupled with the reassurance of quality and reliability.
  •
  • Swift Responses: We prioritize your queries, guaranteeing responses within a 24-hour window.
  • Competitive Pricing: Secure premium-quality products without compromising on your budget, thanks to our compelling pricing strategies.
  •
  • Manufacturer's Assurance: Benefit from the assurance of quality and dependability that comes with direct manufacturer procurement.
  •
  • Client-focused Approach: At the core of our operations is a commitment to fulfilling your specific requirements, driving a mission that revolves around customer satisfaction.
  •

Denso High Voltage Water Heater 15kw 25kW DC 100W 3





Competitive Advantages:



  • Safety and Reliability: Our products undergo stringent quality inspections, ensuring a stellar safety profile and reliable performance across various operational scenarios.
  •
  • Tailored Solutions: Make the most of our OEM services, allowing for adjustments to suit your unique design criteria.
  •
  • Consistent Performance: Our products are renowned for their consistent performance, offering a resilient and dependable ally in your research initiatives.
  •
  • Weather Resilience: Our products demonstrate exceptional resistance to adverse weather conditions, delivering excellent insulation properties and resistance to dry burning, thereby promising a longer operational lifespan.
  •
  • High-Voltage and High-Power Excellence: Our heaters represent the zenith of high voltage and power capabilities, blended with intelligence and reliability, affording a distinct competitive edge in the market.
