Product Details
Place of Origin: CHINA
Brand Name: EVPTC
Certification: CE
Model Number: K
Payment & Shipping Terms
Minimum Order Quantity: 1 SET
Price: $200-500 per set
Packaging Details: carton or wooden case packing
Delivery Time: 15-20days
Payment Terms: T/T
Supply Ability: 100 sets per 2 weeks
Heat Output: |
8-12KW |
HV Voltage Range: |
DC 250-870V |
LV Voltage: |
DC 24V Nominal |
Efficiency: |
> 95 % |
Controllability Steps: |
1% |
Temperature Range For Heating: |
-40 To 90 ℃ |
Temperature Range For Ambient: |
-40 To 125 ℃ |
Communication: |
CAN OR LIN |
Dielectric Strength: |
3500 V (DC) |
IP Protection Class: |
IP 67 |
EMC: |
ECE R10 Rev. 5 |
Insulation Resistance: |
＞500MΩ |
Service Life: |
10 Years Or 10,000 Heating Hours |
Heat Output: |
8-12KW |
HV Voltage Range: |
DC 250-870V |
LV Voltage: |
DC 24V Nominal |
Efficiency: |
> 95 % |
Controllability Steps: |
1% |
Temperature Range For Heating: |
-40 To 90 ℃ |
Temperature Range For Ambient: |
-40 To 125 ℃ |
Communication: |
CAN OR LIN |
Dielectric Strength: |
3500 V (DC) |
IP Protection Class: |
IP 67 |
EMC: |
ECE R10 Rev. 5 |
Insulation Resistance: |
＞500MΩ |
Service Life: |
10 Years Or 10,000 Heating Hours |
|
HVCH K Series |
Specification |
| Heat Output | 8-12kW |
| High Voltage Range | DC 350-900V |
| Low Voltage | DC 24V nominal |
| Efficiency | > 95% |
| Controllability Steps | 100W |
| Weight | 3kg |
| Heating Temperature Range | -40 to 90℃ |
| Ambient Temperature Range | -40 to 125℃ |
| Communication | CAN or LIN2.1 |
| Dielectric Strength | 3500V (DC) |
| IP Protection Class | IP 67 |
| EMC | ECE R10 Rev. 5 |
| Insulation Resistance | >500MΩ |
| Service Life | 10 years or 10,000 hours |
Technical Introduction
EVLINK, as a global leader in automotive market innovation and sustainable mobility solutions, possesses high-voltage coolant heater (HVCH) technology with ceramic insulated PTC. The B-series and Q-series high-voltage electric heaters provided by EVLINK have already captured 70% of the Chinese heavy-duty truck market, demonstrating our outstanding contributions and leadership position in the electric heavy-duty truck field.
Market Position and Partnerships
In August 2023, EVLINK formed a strategic partnership with a renowned Chinese heavy-duty truck manufacturer to provide advanced 870V HVCH electric heater technology for their new electric vehicle models. The 870V HVCH technology from EVLINK serves as a complement to the existing 600V coolant heaters, featuring enhanced electronic functionalities and reliable design and mechanical functionalities, laying a solid foundation for manufacturers in the new electrification field.
Product Features
EVLINK's coolant heaters feature compact modular design, reducing packaging size and weight, ensuring consistent temperature distribution in battery packs and vehicles, thus enhancing battery energy performance. EVLINK's advanced battery and cabin heater systems have gained widespread recognition from domestic OEMs, demonstrating their excellent efficiency and performance.
Application Scenarios
EVLINK's coolant heater is an ideal heating system for plug-in hybrid vehicles and electric vehicles. It converts DC electric power into heat with up to 98% thermal efficiency. Utilizing innovative technology, ceramic insulated materials, and custom PTC components, EVLINK's heater core achieves extremely fast heating times, high precision, and maximum efficiency.
Advantages and Competitiveness
By using EVLink electric heaters, competitive heater suppliers! For more information, please visit our official website: EVLINK official website. HVCH high-voltage coolant heater is an economical and efficient solution designed to improve battery performance, extend driving range, accelerate charging speed, and enhance cabin comfort. With its compact modular design, high thermal power density, and rapid response time, the HVCH pressure coolant heater represents a significant advancement in electric vehicle technology.
Industry Leadership Position
EVLINK has won two more awards for high-voltage electric heater technology. It has reached a business cooperation with a well-known Chinese heavy-duty truck manufacturer to provide advanced high-voltage electric heaters (HVCH) for its new electric vehicle models. The 800V HVCH from EVLINK complements the existing 600V coolant heater with enhanced electronic equipment and reliable design, laying a solid foundation for future business growth.
Future Outlook
EVLINK will continue to focus on providing innovative and sustainable solutions for the automotive industry to create a better driving and riding experience for customers.
