Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW

Certification
China Suzhou EVLINK Electronic Technology Co.,Ltd certification
I'm Online Chat Now

Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW

Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW
Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW

Large Image :  Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW

Product Details:
Place of Origin: CHINA
Brand Name: EVPTC
Certification: CE
Model Number: QA
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: $1200-1500 per set
Packaging Details: carton or wooden case packing
Delivery Time: 15-20days
Payment Terms: T/T
Supply Ability: 100 sets per 2 weeks

Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW

Description
Heat Output: 15-25KW HV Voltage Range: DC 250-870V
LV Voltage: DC 24V Nominal Efficiency: > 95 %
Controllability Steps: 1% Dimensions: 365*313*123mm
Weight: 9kg Temperature Range For Heating: -40 To 90 ℃
Temperature Range For Ambient: -40 To 125 ℃ Communication: CAN OR LIN
Dielectric Strength: 3500 V (DC) IP Protection Class: IP 67
EMC: ECE R10 Rev. 5 Insulation Resistance: >500MΩ
Service Life: 10 Years Or 10,000 Heating Hours
High Light:

automotive coolant heater

,

high voltage ptc heater

,

PTC Heaters DC

EVLINK's HVCH QA01 Series: The Premier Choice for Automotive High Voltage PTC Heaters

Product Introduction:



Distinctively positioned, EVLINK's HVCH QA01 Series represents not just the pinnacle of automotive high voltage PTC heaters but is backed by a wholly indigenous R&D team. We are more than just a supplier; we are a fusion of innovation and quality, dedicated to providing the automotive industry with highly customized solutions.







Specification:



HVCH QA01 Series
Heat Output     15-25kW
HV Voltage Range     DC 250-870V

LV Voltage

  DC 24V nominal
Efficiency     > 95 %
Controllability Steps     100W
Dimensions     365*313*123mm
Weight     9kg
Temperature Range for Heating     -40 to 90 ℃
Temperature Range for Ambient     -40 to 125 ℃
Communication     CAN or LIN2.1
Dielectric Strength     3500 V (DC)
IP Protection Class     IP 67
EMC     ECE R10 Rev. 5
Insulation Resistance     >500MΩ
Service Life     10 years or 10,000 heating hours









Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW 0

Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW 1











Product Attributes:

  •
  •
  • Superior Water Resistance: Whether navigating wet terrains or accidental splashes, our heater stands resilient. We provide IP 67 water and dustproof reports for validation.
  •
  • Precision in Performance: The heater adjusts the water outlet temperature and also restricts the maximum heat output or power consumption.
  •
  • Dual-layered Security: Incorporates both mechanical and electronic safety systems, guarding against potential hazards.
  •
  • Total Insulation: Achieves a complete separation of water and electricity, a vital element for automotive devices.
  • Cutting-edge PTC Technology: Employs PTC technology, dynamically adjusting power while ensuring it never surpasses a set temperature threshold.



Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW 2







Applications:



EVLINK's HVCH QA01 Series has become the go-to choice for numerous automotive manufacturers, thanks to our adherence to automotive development standards and our penchant for customization. Be it testing thermal management units, simulating battery heating, or ensuring rapid start-ups in ultra-low temperatures, our heater perfectly meets the requirements. Moreover, the custom heating strategies we provide for customers, bolstered by our reputation in the automotive industry, makes EVLINK's heaters the most preferred.





Automotive Coolant Heater High Voltage PTC Heaters DC 15-25kW 3





Our Services:





Direct Procurement: Directly catering to your needs, eliminating middlemen, and reducing costs.



Bulk Order Discounts: Significant orders come with substantial discounts.



Prompt Responses: Assured response to inquiries within 24 hours.



Competitive Pricing: Offering top-tier products at reasonable rates.



Manufacturer's Assurance: Direct from the source, ensuring quality and reliability.



Customer-centric Approach: Your requirements, our mission.





Competitive Advantages:





Safety and Reliability: Through rigorous quality controls.



Custom Solutions: Tailoring products based on your unique requirements.



Unwavering Performance: Consistency is our middle name.



Weather Resilient: Waterproof and dustproof, ensuring longevity.



Dry Burning Resistant: Engineered to prevent dry burning.



Compliant with EMC Requirements: Our products fully meet electromagnetic compatibility requirements, ensuring stable operations in any environment.
