Product Details:
Place of Origin: CHINA
Brand Name: EVPTC
Certification: CE
Model Number: QA
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: $1200-1500 per set
Packaging Details: carton or wooden case packing
Delivery Time: 15-20days
Payment Terms: T/T
Supply Ability: 100 sets per 2 weeks

EVLINK's 600V30KW PTC Electric Heater: Resolving Winter Woes with CAN Control PTC heater aluminum die-cast shell

Description
Heat Output: 15-25KW HV Voltage Range: DC 250-870V
LV Voltage: DC 24V Nominal Efficiency: > 95 %
Controllability Steps: 1% Dimensions: 365*313*123mm
Weight: 9kg Temperature Range For Heating: -40 To 90 ℃
Temperature Range For Ambient: -40 To 125 ℃ Communication: CAN OR LIN
Dielectric Strength: 3500 V (DC) IP Protection Class: IP 67
EMC: ECE R10 Rev. 5 Insulation Resistance: >500MΩ
Service Life: 10 Years Or 10,000 Heating Hours





EVLINK's 600V30KW PTC Electric Heater: Resolving Winter Woes with CAN Control PTC heater aluminum die-cast shell 0

In recent weeks, Beijing has experienced an unprecedented onslaught of cold waves, with temperature drops rarely seen in recent years. The extreme cold has become a hot topic, affecting not only electric car drivers facing rapid battery consumption but also citizens traveling on electric buses who feel the biting chill. From January 6th to January 14th, the city's service hotline 12345 has been inundated with citizens' complaints, with over 200 reports of "some buses not using air conditioning or heating, especially new energy electric buses," and "it's too cold on the bus." In response to this issue, our journalists conducted an investigation.

EVLINK's 600V30KW PTC Electric Heater: Resolving Winter Woes with CAN Control PTC heater aluminum die-cast shell 1



1. Winter Challenges for Electric Buses and Vehicles

The severe winter weather has presented challenges for electric vehicles, leading to increased energy consumption and discomfort for passengers. Numerous complaints highlight the urgent need for effective heating solutions in electric buses, especially during freezing temperatures.

2. EVLINK's PTC Heaters: A Solution for Winter Woes

EVLINK's PTC heaters, with a remarkable capacity of 20KW, provide an innovative solution to address the winter-related issues faced by electric vehicles. These heaters not only generate sufficient warmth for the cabin but also incorporate an automatic adjustment feature to optimize energy consumption. The energy-saving functionality of EVLINK's PTC heaters, based on real-time adjustments according to the water temperature in the heating system and the interior temperature of the vehicle, surpasses conventional heaters in terms of efficiency.



EVLINK's 600V30KW PTC Electric Heater: Resolving Winter Woes with CAN Control PTC heater aluminum die-cast shell 2



3. The Power of PTC Heaters in Energy Efficiency

The advanced energy-saving features of EVLINK's PTC heaters play a pivotal role in conserving power during winter. By intelligently regulating the heating process, these heaters ensure a comfortable temperature inside the vehicle while minimizing the impact on overall battery consumption.



EVLINK's 600V30KW PTC Electric Heater: Resolving Winter Woes with CAN Control PTC heater aluminum die-cast shell 3



4. Global Recognition and Export Success

EVLINK's commitment to innovation and addressing winter-related challenges has earned recognition globally. Collaborating with major OEMs, EVLINK has successfully exported its PTC heaters to countries such as South Korea, Norway, France, the United States, and more. This international acclaim underscores the effectiveness and reliability of EVLINK's PTC heaters in diverse climates.





HVCH QA01 Series
Heat Output     15-25kW
HV Voltage Range     DC 250-870V

LV Voltage

  DC 24V nominal
Efficiency     > 95 %
Controllability Steps     100W
Dimensions     365*313*123mm
Weight     9kg
Temperature Range for Heating     -40 to 90 ℃
Temperature Range for Ambient     -40 to 125 ℃
Communication     CAN or LIN2.1
Dielectric Strength     3500 V (DC)
IP Protection Class     IP 67
EMC     ECE R10 Rev. 5
Insulation Resistance     >500MΩ
Service Life     10 years or 10,000 heating hours
