Ptc Coolant Heater Ev For Large Electric Vehicles Bus

Certification
China Suzhou EVLINK Electronic Technology Co.,Ltd certification
I'm Online Chat Now

Ptc Coolant Heater Ev For Large Electric Vehicles Bus

Ptc Coolant Heater Ev For Large Electric Vehicles Bus
Ptc Coolant Heater Ev For Large Electric Vehicles Bus Ptc Coolant Heater Ev For Large Electric Vehicles Bus Ptc Coolant Heater Ev For Large Electric Vehicles Bus Ptc Coolant Heater Ev For Large Electric Vehicles Bus Ptc Coolant Heater Ev For Large Electric Vehicles Bus

Large Image :  Ptc Coolant Heater Ev For Large Electric Vehicles Bus

Product Details:
Place of Origin: CHINA
Brand Name: EVPTC
Certification: CE
Model Number: QA
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: $1200-1500 per set
Packaging Details: carton or wooden case packing
Delivery Time: 15-20days
Payment Terms: T/T
Supply Ability: 100 sets per 2 weeks

Ptc Coolant Heater Ev For Large Electric Vehicles Bus

Description
Heat Output: 15-25KW HV Voltage Range: DC 250-870V
LV Voltage: DC 24V Nominal Efficiency: > 95 %
Controllability Steps: 1% Dimensions: 365*313*123mm
Weight: 9kg Temperature Range For Heating: -40 To 90 ℃
Temperature Range For Ambient: -40 To 125 ℃ Communication: CAN OR LIN
Dielectric Strength: 3500 V (DC) IP Protection Class: IP 67
EMC: ECE R10 Rev. 5 Insulation Resistance: >500MΩ
Service Life: 10 Years Or 10,000 Heating Hours
High Light:

ptc heater ev

,

ptc heater for electric vehicles

,

ptc heater for bus

Resilient and Efficient EVLINK PTC Heaters with Exceptional Safety Features for Large Commercial Vehicles



  1. The PTC Heater for Electric Vehicles is resistant to temperature extremes, providing reliable heating performance in both cold and hot climate conditions.
  2. It offers robust thermal management capabilities, ensuring efficient heating without compromising the overall performance of the electric vehicle.
  3. The heater is compatible with different EV battery chemistries, including lithium-ion, nickel-metal hydride, and solid-state batteries.



Ptc Coolant Heater Ev For Large Electric Vehicles Bus 0



Product Introduction:





As the cold season approaches, securing steady and robust warmth in big commercial vehicles is a vital consideration. Introducing the EVLINK HVCH QA01 Series, a revolutionary interior heater specifically crafted to cater to this demand. Beyond merely heating water circuits, this unit flexibly fine-tunes its performance, promising rapid, reliable, and powerful heating on every occasion.





Specification:



HVCH QA01 Series
Heat Output     15-25kW
HV Voltage Range     DC 250-870V

LV Voltage

  DC 24V nominal
Efficiency     > 95 %
Controllability Steps     100W
Dimensions     365*313*123mm
Weight     9kg
Temperature Range for Heating     -40 to 90 ℃
Temperature Range for Ambient     -40 to 125 ℃
Communication     CAN or LIN2.1
Dielectric Strength     3500 V (DC)
IP Protection Class     IP 67
EMC     ECE R10 Rev. 5
Insulation Resistance     >500MΩ
Service Life     10 years or 10,000 heating hours









Ptc Coolant Heater Ev For Large Electric Vehicles Bus 1

Ptc Coolant Heater Ev For Large Electric Vehicles Bus 2







Product Attributes:







Superior Water Resistance: Crafted to excel even in the harshest conditions, our high-voltage coolant heater braves through muddy terrains and heavy rains with unparalleled waterproof capabilities, substantiated by IP 67 certification.



Flexible Performance: Having served in thousands of vehicles over several years, this coolant heater has earned a sterling reputation for its premium quality and adaptable performance.



Advanced Safety Measures: Featuring dual-layered safety mechanisms that spring into action during short circuits or over-temperature scenarios. Our design enhances safety by including high-voltage relays and current fuses in the circuit, preventing any mishaps.



Complete Electric-Water Separation: Achieving a perfect balance between heat transmission efficiency and insulation requirements of DC 3500V, we ensure absolute separation of electrical components and water, eliminating any risk of short circuits.



Innovative PTC Technology: Embracing the benefits of PTC heating technology, our coolant heater autonomously adjusts power output, maintaining an optimal temperature without the need for additional switching elements, promoting energy efficiency and operational reliability.







Ptc Coolant Heater Ev For Large Electric Vehicles Bus 3











Applications:







EVLINK heaters stand as a beacon of safety and reliability in the market, overshadowing traditional electric heaters which are prone to burnouts. Utilized by well-renowned firms and national laboratories, they have become an essential tool in the industry. It is noteworthy to mention that our heaters were prominently used in vehicles assigned to journalists during the 2022 Beijing Winter Olympics, receiving universal acclaim.







Ptc Coolant Heater Ev For Large Electric Vehicles Bus 4





Our Services:



Direct Procurement: Facilitating direct supply to eliminate additional agency fees and reduce your costs significantly.



Bulk Order Discounts: We offer enticing discounts for bulk orders, with provisions for trial orders.



Swift Responses: Guaranteeing a response time of merely 24 hours for all your inquiries.



Competitive Pricing: Providing premium products at reasonable prices, ensuring value for your investment.



Manufacturer's Expertise: As seasoned manufacturers, we are equipped to cater to all your requirements with precision and excellence.



Customer-Centric Approach: We prioritize your needs, dedicating ourselves to exceed your expectations at every stage of the collaboration.





Competitive Advantages:



Adaptive Resilience to Climate: Our products are designed to excel across varied climatic conditions, providing excellent insulation and preventing dry burning, thereby ensuring adaptability and durability.



Customized Solutions: We specialize in OEM services, modifying our products to match your specific design needs, delivering bespoke solutions every time.



Reliable and Consistent Performance: Celebrated for their steadfast performance, our products are engineered to withstand diverse environmental conditions, promising a long and reliable service life.



High-Voltage and High-Power Superiority: Symbolizing the harmonious blend of high voltage, power, and intelligence, our heaters offer an unmatched competitive edge in the market.



Guaranteed Safety and Reliability: Our products undergo rigorous quality evaluations, assuring safety and dependability even in the most challenging conditions.
