EVLINK Electronic Co.,Ltd 13004587611@evptc.com 86-130-04587611
Product Details
Place of Origin: CHINA
Brand Name: EVPTC
Certification: CE
Model Number: QA
Payment & Shipping Terms
Minimum Order Quantity: 1 SET
Price: $1200-1500 per set
Packaging Details: carton or wooden case packing
Delivery Time: 15-20days
Payment Terms: T/T
Supply Ability: 100 sets per 2 weeks
Heat Output: |
15-25KW |
HV Voltage Range: |
DC 250-870V |
LV Voltage: |
DC 24V Nominal |
Efficiency: |
> 95 % |
Controllability Steps: |
1% |
Dimensions: |
365*313*123mm |
Weight: |
9kg |
Temperature Range For Heating: |
-40 To 90 ℃ |
Temperature Range For Ambient: |
-40 To 125 ℃ |
Communication: |
CAN OR LIN |
Dielectric Strength: |
3500 V (DC) |
IP Protection Class: |
IP 67 |
EMC: |
ECE R10 Rev. 5 |
Insulation Resistance: |
＞500MΩ |
Service Life: |
10 Years Or 10,000 Heating Hours |
Heat Output: |
15-25KW |
HV Voltage Range: |
DC 250-870V |
LV Voltage: |
DC 24V Nominal |
Efficiency: |
> 95 % |
Controllability Steps: |
1% |
Dimensions: |
365*313*123mm |
Weight: |
9kg |
Temperature Range For Heating: |
-40 To 90 ℃ |
Temperature Range For Ambient: |
-40 To 125 ℃ |
Communication: |
CAN OR LIN |
Dielectric Strength: |
3500 V (DC) |
IP Protection Class: |
IP 67 |
EMC: |
ECE R10 Rev. 5 |
Insulation Resistance: |
＞500MΩ |
Service Life: |
10 Years Or 10,000 Heating Hours |
Introduction to EVLINK Heaters:
EVLINK's PTC liquid heater employs cutting-edge relay and IGBT technology to provide efficient and reliable heating solutions for electric buses. Specifically designed to maintain core warmth in extremely cold European climates while ensuring a warm interior, its intelligent PID system enhances the energy efficiency of electric buses, creating a more comfortable riding experience for passengers.
Product Attributes:
EVLINK's PTC liquid heater boasts an IP67 protection rating and supports multilingual technical coordination. Our dedicated team independently formulates heating solutions, ensuring exceptional product quality. The obtained EMC certificate validates the high performance and electromagnetic compatibility of the product.
Applications:
EVLINK's PTC liquid heater has been successfully introduced to the market, widely applied in electric buses and other fields. Compared to the traditional Thermo DC 200, our 30kW heater offers greater power at a more competitive price. This positions EVLINK with a unique competitive advantage in the international market.
Service and Competitive Edge:
In early 2024, EVLINK signed strategic cooperation agreements with major OEMs, customizing a semi-automatic production line for QA coolant heaters and driving improvements in production and quality levels. With unparalleled dedication and expertise, we provide customers with the highest quality service. We will continue to innovate, striving to meet the growing demands of the market.
Specification:
| HVCH QA01 Series | |
| Heat Output | 15-25kW |
| HV Voltage Range | DC 250-870V |
|
LV Voltage |
DC 24V nominal |
| Efficiency | > 95 % |
| Controllability Steps | 100W |
| Dimensions | 365*313*123mm |
| Weight | 9kg |
| Temperature Range for Heating | -40 to 90 ℃ |
| Temperature Range for Ambient | -40 to 125 ℃ |
| Communication | CAN or LIN2.1 |
| Dielectric Strength | 3500 V (DC) |
| IP Protection Class | IP 67 |
| EMC | ECE R10 Rev. 5 |
| Insulation Resistance | ＞500MΩ |
| Service Life | 10 years or 10,000 heating hours |
Service and Competitive Advantage:
At EVLINK, our dedication to quality extends beyond delivering outstanding products; it encapsulates a holistic commitment to customer satisfaction. We prioritize understanding and addressing the unique needs of our customers, aiming to establish industry standards for service excellence.
Our competitive edge is forged through an unwavering commitment to innovation, product quality, and customer-centric service. Looking ahead, EVLINK is poised to meet the dynamic demands of the market with unmatched dedication and expertise.
