Electric Water High Voltage Ptc Coolant Heater

Electric Water High Voltage Ptc Coolant Heater
Electric Water High Voltage Ptc Coolant Heater Electric Water High Voltage Ptc Coolant Heater Electric Water High Voltage Ptc Coolant Heater

Large Image :  Electric Water High Voltage Ptc Coolant Heater

Product Details:
Place of Origin: CHINA
Brand Name: EVPTC
Certification: CE
Model Number: AZ01
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: $1500-2000 per set
Packaging Details: carton or wooden case packing
Delivery Time: 15-20days
Payment Terms: T/T
Supply Ability: 100 sets per 2 weeks

Electric Water High Voltage Ptc Coolant Heater

Description
Heat Output: 8-18kW HV Voltage Range: DC 350-870V
LV Voltage: DC 24V Or 12V Nominal Efficiency: > 95 %
Controllability Steps: 1% Dimensions: 340*138*125mm
Weight: 6kg Temperature Range For Heating: -40 To 90 ℃
Temperature Range For Ambient: -40 To 125 ℃ Communication: CAN OR LIN
Dielectric Strength: 3500 V (DC) IP Protection Class: IP 67
EMC: ECE R10 Rev. 5 Insulation Resistance: >500MΩ
Service Life: 10 Years Or 10,000 Heating Hours
High Light:

Water Ptc Coolant Heater

,

High voltage Ptc Coolant Heater

,

Water Ptc Heater

  1. The PTC Coolant Heater provides precise temperature control, allowing users to maintain the desired coolant temperature according to specific requirements.
  2. It offers uniform and consistent heating throughout the coolant system, ensuring efficient heat transfer and distribution.
  3. The heater is compatible with various coolant types, including water-based and glycol-based solutions, catering to different application needs.



Electric Water High Voltage Ptc Coolant Heater 0

HVCH AZ01 Series







The EVLINK AZ01 Series of high voltage coolant heaters has been operating stably in hundreds of different scenarios for over three years. One such application is its integration into the thermal management system of hybrid power units in collaboration with CRRC Corporation Limited, a renowned Chinese rolling stock manufacturer. Serving as a critical component for battery pre-heating within these units, EVLINK's high voltage coolant heater has bridged the domestic gap for high-power, compact designs, positioning it at the forefront of national advancements.









Specification:



HVCH AZ01 Series
Heat Output     8-18kW
HV Voltage Range     DC 350-870V

LV Voltage

  DC 24V or 12V nominal
Efficiency     > 95 %
Controllability Steps     100W
Dimensions     340*138*125mm
Weight     6kg
Temperature Range for Heating     -40 to 90 ℃
Temperature Range for Ambient     -40 to 125 ℃
Communication     CAN or LIN2.1
Dielectric Strength     3500 V (DC)
IP Protection Class     IP 67
EMC     ECE R10 Rev. 5
Insulation Resistance     >500MΩ
Service Life     10 years or 10,000 heating hours







Electric Water High Voltage Ptc Coolant Heater 1













Product Features:







Robust Power and Exceptional Compatibility: Expertly designed to deliver heating solutions ranging from 10KW to 18KW, the EVLINK heater promises an unmatched cozy ambiance for its users.



Revolutionary Compact Structure: Standing distinctively in the market, its compact stature compared to other heaters with equivalent power output provides more leeway in vehicle installation configurations, enhancing the overall adaptability and integration process.



Pioneering Structural Innovation: The distinctive architecture of the EVLINK heater not only stands as a testament to efficiency but also as a beacon of stability, setting it a class apart in the sector.



Unmatched Versatility in Diverse Environments: With a special emphasis on larger vehicles such as buses, the EVLINK heater stands as a versatile choice, consistently delivering a warm and comforting experience to passengers, regardless of the external weather conditions.





Electric Water High Voltage Ptc Coolant Heater 2







Application:





Our collaboration with CRRC Corporation Limited stands as a testament to the versatility and efficiency of the AZ01 series. Integrated into hybrid power units, it plays a pivotal role in ensuring optimal temperature management for battery systems, thereby enhancing the overall performance and longevity of the units.











Electric Water High Voltage Ptc Coolant Heater 3







Our Services:





Strategic Collaborations: We pride ourselves on forming strategic partnerships, like that with CRRC Corporation Limited, to push the boundaries of thermal management.



Consistent Performance: With over three years of proven stability in diverse settings, our products stand the test of time.



Customized Solutions: Tailored to meet the unique demands of every scenario, we ensure optimal performance in every context.



Leading the Domestic Market: Our innovative designs have filled a critical gap in the domestic market, making us pioneers in the field.







Competitive Advantage:





Proven Reliability: Our long-standing stability in various applications speaks volumes about our product's reliability.



Strategic Collaborations: Partnerships with industry giants like CRRC Corporation Limited enhance our credibility and market reach.



Innovative Designs: We constantly push the envelope with our designs, ensuring compactness without compromising on power.



National Pioneers: Filling a crucial void in the domestic market, we've established ourselves as national leaders in high-power, compact coolant heating solutions.
